Hantek 6052BE Oscilloscope USB 2 canaux / 50MHZ
201.32 €
241,58 € TVA INCLUSE
Oscilloscope USB pour PC, 2 canaux.
Bande passante de 50MHZ.
Léger et compact, il transforme n'importe quel PC en oscilloscope complet.
Boîtier en aluminium, léger et résistant.
Alimentation USB (Aucune alimentation externe requise).
Compatible avec le standard USBXI (TM).
Hantek 6052BE Oscilloscope USB 2 canaux / 50MHZ
Features
- USB Oscilloscope.
- 2 Channels.
- 50MHZ bandwidth.
- High performance, 150MS/s real-time sampling.
- Standard USBXITM interface, easily inserts into USBXITM housing to make up a combination instrument.
- USB2.0 interface, no external power source required, easy to use.
- Be suitable for notebook computer, product line maintenance, be used easily on business.
- Dimensions (mm):205(L) x120(W) x35(H), be carried easily.
- Operating System: Windows 10, Windows 8, Windows 7, Windows NT, Windows XP, VISTA.
- 23 measurement functions, PASS/FAIL Check, be suitable for technical application.
- Waveform average, persistence, intensity, invert, addition, subtraction, multiplication, division, X-Y plot.
- Save waveform in the following: text file, jpg/bmp graphic file, MS excel/word file.
- FFT
- One computer can connect many DSO, extend channel easily.
- Labview,VB,VC, SDK libraries.
|
Model |
Hantek 6022BE |
Hantek 6052BE |
Hantek 6082BE |
Hantek 6102BE |
Hantek 6212BE |
|
|
Channel |
2 Channels |
|||||
|
Bandwidth |
20MHz |
50MHz |
80MHz |
100MHz |
200MHz |
|
|
Input Impedance |
1MΩ 25pF |
|||||
|
Max. Sample rate |
48MS/s |
150MS/s |
250MS/s |
250MS/s |
250MS/s |
|
|
Coupling |
DC |
AC/DC/GND |
||||
|
Vertical resolution |
8Bit |
|||||
|
Gain range |
10mV-5V, 9Steps |
|||||
|
DC accuracy |
±3% |
|||||
|
Timebase range |
4ns-5ks |
4ns-1h, 38 Steps |
||||
|
Vertical adjustable |
Yes |
|||||
|
Input protection |
Diode clamping |
|||||
|
X-Y |
Yes |
|||||
|
EXT. input |
No |
Yes |
||||
|
Trigger Mode |
Auto, Normal and Single |
|||||
|
Trigger Slope |
+/- |
|||||
|
Trigger level adjustable |
Yes |
|||||
|
Trigger Type |
Rising edge, falling edge |
|||||
|
Trigger Source |
CH1, CH2 |
CH1, CH2, EXT |
||||
|
Pre/Post trigger |
0-100% |
|||||
|
Buffer size |
1M |
10K-64KB/Channel |
||||
|
Sampling selection |
Yes |
|||||
|
Waveform Display |
port/line, waveform average, persistence, intensity |
|||||
|
Network |
Open/Close |
|||||
|
Vertical mode |
CH1, CH2, Dual, ADD |
|||||
|
Cursor measurement |
Yes |
|||||
|
Math |
FFT, addition, subtraction, multiplication, division. |
|||||
|
Cursor |
Frequency, Voltage |
|||||
|
Accessories |
S/W CD, probes, manual, USB cord |
|||||
6052BE
Fiche technique
- Canaux d'oscilloscope
- 2
- Bande passante de l'oscilloscope
- 50
